TEIN Flex Z Coilovers for Toyota C-HR

Transform the suspension of your Toyota C-HR with the TEIN Flex Z Coilover Kit VSTE0-C1AA3.

TEIN FLEX Z is designed to deliver an excellent balance between sporty handling, adjustable ride height and everyday ride comfort. Rather than simply fitting stiffer lowering springs, FLEX Z replaces the vehicle’s dampers and springs with a matched adjustable suspension system.

For C-HR owners looking to reduce arch gap, sharpen handling and create a more purposeful stance while retaining good road manners, FLEX Z is an excellent upgrade.

16-Level Adjustable Damping

FLEX Z features 16-stage damping force adjustment, allowing the driver to alter compression and rebound characteristics together.

This allows the suspension to be set softer for everyday road driving or progressively firmer when greater body control and sharper response are required.

Full-Length Ride Height Adjustment

TEIN uses a full-length ride-height adjustment system that changes the overall damper length rather than relying solely on spring preload.

This allows ride height to be altered with minimal effect on usable damper stroke, helping retain ride comfort and suspension performance even when the vehicle is lowered.

Twin-Tube Damper Construction

The FLEX Z uses TEIN’s twin-tube damper design.

Twin-tube construction allows generous suspension stroke while operating at relatively low gas pressure, helping the suspension respond smoothly to uneven UK road surfaces.

The result is a suspension setup capable of providing a compliant ride at lower speeds while improving stability and body control during faster driving.

Designed for Street Performance

TEIN specifically developed FLEX Z as a road-orientated adjustable coilover system.

Compared with the standard C-HR suspension, the system can help reduce:

• Excessive body roll
• Floating or unsettled suspension movement
• Wheel-arch gap
• Slow suspension response
• Excessive pitch during acceleration and braking

At the same time, the adjustable damping gives the owner substantially more control over how the vehicle feels.

EDFC Compatible

The kit is compatible with the TEIN EDFC electronic damping force controller system where applicable.

TEIN specifically recommends EDFC for this C-HR application because access to the damping adjusters can be difficult once installed.

Please note that EDFC components are normally purchased separately unless specifically stated otherwise.

Key Features

• Genuine TEIN FLEX Z suspension kit
• Part number: VSTE0-C1AA3
• Complete front and rear coilover suspension kit
• 16-level damping force adjustment
• Full-length ride-height adjustment
• Twin-tube damper construction
• Matched TEIN springs
• Designed for improved road handling and comfort
• Adjustable vehicle stance
• EDFC compatible where applicable
• Manufactured by TEIN
• Designed and developed for vehicle-specific installation
• Suitable for selected Toyota C-HR models
• Selected Toyota C-HR GR Sport fitment
• Ideal for road and fast-road use

TEIN Verified Application Information

TEIN lists VSTE0-C1AA3 for several Toyota C-HR applications, including:

Toyota C-HR NGX10
1.2-litre turbo, front-wheel drive

Toyota C-HR NGX50
1.2-litre turbo, four-wheel drive

Toyota C-HR ZYX10
1.8-litre hybrid

Toyota C-HR ZYX11
1.8-litre hybrid

Toyota C-HR GR Sport NGX10
Selected 1.2-litre turbo models

Toyota C-HR GR Sport ZYX11
Selected 1.8-litre hybrid models

Fitment should always be checked against the vehicle’s chassis code before ordering.

Important: UK-market engine and trim availability differs from TEIN’s Japanese catalogue. Do not assume compatibility with a 2.0 Hybrid M20A-FXS C-HR / GR Sport solely because the vehicle is a first-generation C-HR. Contact us with your registration or chassis details if unsure.

Suspension Specifications

Product Range: TEIN FLEX Z
Manufacturer: TEIN
Manufacturer Part Number: VSTE0-C1AA3
Damper Type: Twin-Tube
Damping Adjustment: 16-Level
Ride Height Adjustment: Full-Length Adjustable
Front Spring Rate: 5.0 kgf/mm on the principal listed C-HR applications
Rear Spring Rate: 5.0 kgf/mm on the principal listed C-HR applications
EDFC Compatibility: Yes / application dependent
Vehicle: Toyota C-HR
Chassis: NGX10 / NGX50 / ZYX10 / ZYX11
Product Type: Adjustable Coilover Suspension Kit

Why Choose TEIN Flex Z?

TEIN is one of Japan’s best-known performance suspension manufacturers, with decades of experience developing suspension systems for road cars, motorsport and performance applications.

FLEX Z provides many of the adjustments normally associated with more expensive performance coilovers while retaining a strong focus on road comfort.

For a Toyota C-HR that is used every day but needs a lower stance and more controlled handling, FLEX Z provides an excellent compromise between comfort, looks and performance.

Ideal For

• Toyota C-HR owners wanting adjustable suspension
• Lowered C-HR builds
• C-HR GR Sport suspension upgrades
• Fast-road C-HR builds
• Improved cornering stability
• Reducing body roll
• Improving vehicle stance
• Replacing tired factory dampers with an adjustable performance system
• Drivers wanting adjustable damping
• Owners planning to add TEIN EDFC

Fitment Warning

Vehicle specifications can vary according to model year, engine, transmission, drivetrain and market.

Please confirm your chassis code before ordering.

If you are unsure whether TEIN VSTE0-C1AA3 fits your Toyota C-HR, provide your vehicle registration, year, engine and chassis details before purchase.
